Chemical Tanker Trucks
Sinotruk Howo 14m³ Corrosive Goods Tank Transport Vehicle
Model 5260GFWZ6
Sinotruk Howo 14m³ Corrosive Goods Tank Transport Vehicle configured for specialized liquid transport.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 14.5m³ |
|---|---|
| Tank dimensions | 7300×φ1750mm |
| Rated payload | 14500 kg |
| Overall dimensions | 10030 × 2550 × 3335 mm |
| Gross vehicle mass | 26000 kg |
| Curb weight | 11305 kg |
| Chassis model | ZZ1267N464GF1K |
| Wheelbase | 4575+1400 mm |
| Engine model | MC07.34-60 |
| Engine displacement | 6870 ml |
| Engine power | 251 kW |
| Horsepower | 341 hp |
| Tires | 295/80R22.5 18PR |
| Additional configuration | This is an AT-type dangerous goods transport vehicle. The side and rear protections are both welded (Q235B carbon steel material, rear protection cross-section 140×50mm, ground clearance 480mm). It is equipped with an EBS system, a speed limiter (limited to 80km/h) and a satellite-positioning driving recorder. The front wheels are disc brakes, the exhaust pipe is front-mounted, the rear axle uses air suspension, and only radial tires are used. Configurations such as ETC on-board devices, rear bumpers and tank sizes can be optionally installed. |
| Transport Medium | Corrosive chemicals |
