Chemical Tanker Trucks
FAW Jiefang J6L 9m³ Corrosive Goods Tank Transport Vehicle
Model 5180GFWC6
FAW Jiefang J6L 9m³ Corrosive Goods Tank Transport Vehicle configured for specialized liquid transport.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 9.4m³ |
|---|---|
| Tank dimensions | 5300×φ1600mm |
| Rated payload | 10100 kg |
| Overall dimensions | 8450 × 2486 × 3200 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 7705 kg |
| Chassis model | CA5180GYYYP62K1L5E6 |
| Wheelbase | 4700 mm |
| Engine model | CA4DK1-22E61 |
| Engine displacement | 4764 ml |
| Engine power | 165 kW |
| Horsepower | 224 hp |
| Tires | 275/80R22.5 18PR |
| Additional configuration | This is an AT-type dangerous goods transport vehicle. The side protection is bolt-connected, and the rear protection is bolt-connected (Q235 material, cross-section 120×60mm, ground clearance 420mm). It is equipped with an EBS system, a speed limiter (limited to 79km/h) and a satellite-positioning driving recorder. The front wheels are disc brakes, the exhaust pipe is front-mounted, the rear axle uses air suspension, and only radial tires are used. Configurations such as ETC on-board devices, operation box positions and toolboxes can be optionally installed. |
| Transport Medium | Corrosive chemicals |
