Lubricant Tanker Semi-Trailers
42m³ Lubricating Oil Tank Transport Semi-trailer
Model AKL9400GRH
42m³ Lubricating Oil Tank Transport Semi-trailer configured for lubricant and oil-product transport.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 42m³ |
|---|---|
| Tank dimensions | 11250 × 2482 × 1972 mm |
| Rated payload | 34000Kg |
| Overall dimensions | 11500 × 2500 × 3850 mm |
| Gross vehicle mass | 40000Kg |
| Curb weight | 6000Kg |
| Wheelbase | 5980+1310+1310 mm |
| Tires | 12R22.512PR |
| Additional configuration | It is a non-dangerous goods transport vehicle, with a maximum allowed medium density of 830kg/m³; equipped with ABS, side/rear protection material is aluminum alloy (bolted connection), rear protection section150× 80mm, ground clearance500mm; optional ladder, toolbox, mudguard and other accessories; must be matched with a semi-trailer tractor. |
| Transport Medium | Lubricating oil |
