Lubricant Tanker Semi-Trailers
40m³ Lubricating Oil Tank Transport Semi-trailer
Model PJQ9400GRHB
40m³ Lubricating Oil Tank Transport Semi-trailer configured for lubricant and oil-product transport.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 40.5m³ |
|---|---|
| Tank dimensions | 11550 × 2490 × 2300 mm |
| Rated payload | 31200Kg |
| Overall dimensions | 11900 × 2500 × 3750 mm |
| Gross vehicle mass | 40000Kg |
| Curb weight | 8800Kg |
| Wheelbase | 5800+1310+1310 mm |
| Tires | 12R22.512PR |
| Additional configuration | It is a non-dangerous goods transport vehicle with a double-layer insulated tank, insulation thickness100mm, outer insulation optional matte stainless steel, galvanized sheet, etc.; equipped with ABS, protection material is carbon steel Q235B, rear protection section150×50mm, ground clearance500mm; optional air suspension, ladder, toolbox and other accessories; must be matched with a semi-trailer tractor. |
| Transport Medium | Lubricating oil |
