Lubricant Tanker Semi-Trailers
37m³ Lubricating Oil Tank Transport Semi-trailer
Model CTY9400GRH38
37m³ Lubricating Oil Tank Transport Semi-trailer configured for lubricant and oil-product transport.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 37m³ |
|---|---|
| Tank dimensions | Length9600 mm,Width2500 mm,Front height1910 mm,Rear height2080 mm |
| Rated payload | 31800Kg |
| Overall dimensions | 9900 × 2500 × 3650 mm |
| Gross vehicle mass | 40000Kg |
| Curb weight | 8200Kg |
| Wheelbase | 4650+1310+1310 mm |
| Tires | 12R22.512PR |
| Additional configuration | It is a non-dangerous goods transport vehicle with a gooseneck-type tank; equipped with ABS, protection material is Q235, side/rear protection connected to the vehicle by bolts or welding, rear protection section 120× 68mm, ground clearance 500mm; optional ladder, toolbox, mudguard and other accessories; must be matched with a semi-trailer tractor. |
| Transport Medium | Lubricating oil |
