Fuel Tanker Trucks
Sinotruk Howo 13m³ Light Oil Tanker
Model 5181GYYZ6L
Sinotruk Howo 13m³ Light Oil Tanker configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 13.2m³ |
|---|---|
| Tank dimensions | 4700 × 2100 × 1540 mm |
| Rated payload | 10435 kg |
| Overall dimensions | 8500 × 2550 × 3320 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 7370 kg |
| Chassis model | ZZ1187K501GF1 |
| Wheelbase | 4700 mm |
| Engine model | WP7H245E62 |
| Engine displacement | 6800 ml |
| Engine power | 180 kW |
| Horsepower | 245 hp |
| Tires | 295/80R22.5 18PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 4700×2100×1540mm; The side and rear protections are bolt-connected with aluminum alloy material (cross-section 60×120mm, 490mm above the ground), and the rear protection can also be Q235 material; It is equipped with EBS system, a speed limiter (limited to 80km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, rear axle air suspension, and can be optionally equipped with ETC on-board devices, ladders and fire extinguishers. |
| Transport Medium | Kerosene&Diesel |
