FAW Jiefang J6L 16m³ Oil Transport Truck
Model 5181GYYLC6
FAW Jiefang J6L 16m³ Oil Transport Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Transport medium | Gasoline |
|---|---|
| Tank / body volume | 16m³ |
| Tank dimensions | 5500 × 2350 × 1600 mm |
| Rated payload | 11200 kg |
| Overall dimensions | 8500 × 2500 × 3300 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 6605 kg |
| Chassis model | CA5180GYYYP62K1L5E6 |
| Wheelbase | 4700 mm |
| Engine model | CA4DK1-22E61 |
| Engine displacement | 4764 ml |
| Engine power | 165 kW |
| Horsepower | 224 hp |
| Tires | 275/80R22.5 18PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 5500×2350×1600mm; The side and rear protections are bolt-connected with aluminum alloy material, the rear protection cross-section is 120×60mm with a ground clearance of 450mm; It is equipped with a speed limiter (limited to 79km/h), a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, and can be optionally equipped with ETC, fire extinguisher styles and other configurations. |
