Dongfeng Tianjin 15m³ Carbon Steel Refueling Truck
Model 5185GJY6D
Dongfeng Tianjin 15m³ Carbon Steel Refueling Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 15m³ |
|---|---|
| Tank dimensions | 5720 × 2150 × 1500 mm |
| Rated payload | 10000 kg |
| Overall dimensions | 8500 × 2550 × 3350 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 7805 kg |
| Chassis model | DFH1180EX9 |
| Wheelbase | 4700 mm |
| Engine model | B6.2NS6B210 |
| Engine displacement | 6200 ml |
| Engine power | 154 kW |
| Horsepower | 209 hp |
| Tires | 275/80R22.5 18PR |
| Additional configuration | This vehicle features a National VI Dongfeng Tianjin D530 extended cab standard roof, Cummins B62NS6B210 National VI engine, 8JS85TE-C transmission, 4700mm wheelbase, 250×80×(7+4)mm frame, 4.5T/9T single-reduction front/rear axles, 160L aluminum fuel tank, 275/70R22.5 18PR tires, power windows, driving recorder, original air conditioner and safety systems (air suspension, front-mounted exhaust, front disc-rear drum brakes, ABS air brake, power steering, clutch booster, EBS, FCWS/LDWS, front-axle TPMS); it has a 15m³ dual-medium (diesel/gasoline) tank (5720×2150× 1500mm), overall dimensions 8465×2500×3100mm, single-compartment pump for pump-in/out, full European standard bottom loading parts, 2 oil hoses, flame arrester, blanking caps, toolbox, 1 hazard light, 2 hazard aluminum plates, on-board tools and complete registration documents. |
