Fuel Tanker Trucks
Shacman Delong 8×4 28m³ Oil Transport Truck
Model 5320GYY6SX
Shacman Delong 8×4 28m³ Oil Transport Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Transport medium | Gasoline & Diesel |
|---|---|
| Tank / body volume | 28m³ |
| Tank dimensions | 8900 × 2400 × 1600 mm |
| Rated payload | 18270 kg |
| Overall dimensions | 11730 × 2550 × 3450 mm |
| Gross vehicle mass | 32000 kg |
| Curb weight | 13600 kg |
| Chassis model | SX1329MB6WQ1 |
| Wheelbase | 1800+4375+1400 mm |
| Engine model | WP8.350E61 |
| Engine displacement | 7800 ml |
| Engine power | 257 kW |
| Horsepower | 349 hp |
| Tires | 12R22.5 18PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 8900×2400×1600mm; The side protection is bolt-connected with Q235 material, the rear protection is welded + bolt-connected with Q235 material, the rear protection cross-section is 140×50mm with a ground clearance of 400mm; It is equipped with EBS system, a speed limiter (limited to 79km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, rear axle air suspension, and can be optionally equipped with ETC on-board devices, tank ladder styles and other configurations. |
