Fuel Tanker Trucks
Dongfeng Tianjin 12m³ Oil Transport Truck
Model 5181GYYD5
Dongfeng Tianjin 12m³ Oil Transport Truck configured for fuel and light-oil transport or refuelling.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Transport medium | Gasoline |
|---|---|
| Tank / body volume | 11.9m³ |
| Tank dimensions | 5600 × 1980 × 1380 mm |
| Rated payload | 9905 kg |
| Overall dimensions | 8400 × 2500 × 3100 mm |
| Gross vehicle mass | 18000 kg |
| Curb weight | 7900 kg |
| Chassis model | DFH1180BX5V |
| Wheelbase | 4500 mm |
| Engine model | ISB210 50 |
| Engine displacement | 5900 ml |
| Engine power | 155 kW |
| Horsepower | 210 hp |
| Tires | 10.00R20 18PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 5600×1980×1380mm; The side and rear protections are bolt-connected with Q235B carbon steel, the rear protection cross-section is 120 ×50mm with a ground clearance of 500mm; It is equipped with ABS system, a speed limiter (limited to 80km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, and rear axle air suspension. |
| Special notes | It is equipped with ABS system, a speed limiter (limited to 80 km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes, and rear axle air suspension |
