Asphalt Distributor Trucks
Dongfeng Small Duolika 4m³ Asphalt Distributor Truck
Model 5070GLQE6
A 4m³ asphalt distributor truck for controlled liquid-asphalt spraying in road construction and maintenance.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated payload | 2355 kg |
|---|---|
| Overall dimensions | 6340 × 2060 × 2790 mm |
| Gross vehicle mass | 7360 kg |
| Curb weight | 4810 kg |
| Chassis model | EQ1075SJ3CDF |
| Wheelbase | 3308 mm |
| Engine model | Q23-132E60 |
| Engine displacement | 2300 ml |
| Engine power | 97 kW |
| Horsepower | 131 hp |
| Tires | 7.00R16LT 14PR |
| Special notes | This vehicle is mainly used for road asphalt spreading. The upfit includes a tank and asphalt spraying device for liquid asphalt with a density of 900 kg/m³. The side protection is bolted aluminum alloy; the rear protection is replaced by the working device, with its lower edge 400 mm above the ground. The vehicle is equipped with ABS and uses the 3308 mm-wheelbase chassis only. The cab and optional rear structure are selected with the chassis. Rear lighting is for stationary night operation only and must not be used while driving. |
