Vacuum Trucks
Dongfeng Huashen F3 4m³ Vacuum Sewage Truck
Model 5070GXWE6
Dongfeng Huashen F3 4m³ Vacuum Sewage Truck configured for sewage suction and sanitation work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 3.5m³ |
|---|---|
| Rated payload | 3070 kg |
| Overall dimensions | 5995 × 2000 × 2600 mm |
| Gross vehicle mass | 7360 kg |
| Curb weight | 4495 kg |
| Chassis model | EQ1070GL6DJ |
| Wheelbase | 3300 mm |
| Engine model | D20TCIF11 |
| Engine displacement | 1999 ml |
| Engine power | 93 kW |
| Horsepower | 126 hp |
| Tires | 7.00R16LT 14PR |
| Additional configuration | For sewage suction, core devices: tank (with lifting function)+sewage suction pump, tank total/effective cap.3.5/3.33m³, medium liquid sewage (density800kg/m³), dims(total length×diameter)4000× 1200mm (single tank head length300mm), side protection Q235B bolted, rear protection Q235B welded (section W×H50×120mm, ground clearance400mm), ABS model3550D-1010C2000, modified with 3300mm wheelbase only, chassis-optional cab. |
