Prisoner Transport Vehicles
SAIC MAXUS G20 Prison Van
Model EHY5030XQCS6QT
SAIC MAXUS G20 Prison Van is configured for secure supervised transport in law-enforcement operations.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 5198 × 1980 × 2015 mm |
|---|---|
| Gross vehicle mass | 2900 kg |
| Curb weight | 2080, 2170 kg |
| Chassis model | SH6521C1GD-A |
| Wheelbase | 3198 mm |
| Engine model | ECOBOOST4G20C6L |
| Engine displacement | 1986 ml |
| Engine power | 192 kW |
| Fuel type | Gasoline |
| Emission standard | China 6 (China 6 (GB 18352.6-2016)) |
| Tires | 215/70R16, 215/70R16LT, 225/55R18 |
| Axles | 2 |
| Maximum speed | 195 km/h |
| Rated passengers | 7-9 |
