Ford Transit T6 Diesel Version Inspection Vehicle
Model EHY5040XJCJ6QT
Ford Transit T6 Diesel Version Inspection Vehicle is configured for mobile inspection and technical testing work.
Chassis modelJX5043XXYTFM-M6Engine power105 kW
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 5525, 5341 × 1986, 2055 × 2700, 2680, 2395, 2040 mm |
|---|---|
| Gross vehicle mass | 3510 kg |
| Curb weight | 2650, 2530 kg |
| Chassis model | JX5043XXYTFM-M6 |
| Wheelbase | 3300 mm |
| Engine model | DURATORQ4D20C6H; DURATORQ4D20B6H |
| Engine displacement | 1998 ml |
| Engine power | 105 kW |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 215/75R16LT, 215/75R16C |
| Axles | 2 |
| Maximum speed | 160, 100 km/h |
| Rated passengers | 2, 3 |
