Aircraft Refuellers
Dongfeng Xiaofuruika 4m³ Aircraft Refueling Truck
Model 5070GJYL6
Dongfeng Xiaofuruika 4m³ Aircraft Refueling Truck configured for airport aviation-fuel transfer.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Tank / body volume | 4.85m³ |
|---|---|
| Tank dimensions | 2600 × 1280 × 1280 mm |
| Rated payload | 3650 kg |
| Overall dimensions | 5940 × 2000 × 2700 mm |
| Gross vehicle mass | 7360 kg |
| Curb weight | 3580 kg |
| Chassis model | EQ1075SJ3CDFWXP |
| Wheelbase | 2700 mm |
| Engine model | D20TCIF1 |
| Engine displacement | 1999 ml |
| Engine power | 93 kW |
| Horsepower | 126 hp |
| Tires | 7.00R16LT 14PR |
| Additional configuration | This is an FL-type dangerous goods transport vehicle, with tank external dimensions of 2600×1280×1280mm; The side protection is bolt-connected with aluminum alloy material, the rear protection is welded with Q235B carbon steel (cross-section 120×60mm, 400mm above the ground); It is equipped with ABS system, a speed limiter (limited to 80km/h) and a satellite-positioning driving recorder, front-wheel disc brakes, front-mounted exhaust pipes. |
