Troop Carriers
Jiangling Fushun Troop Carrier
Model 5040XYB6QT
Jiangling Fushun Troop Carrier is configured for organized personnel transport and field deployment.
Chassis modelJX6605TB-N6Engine power107 kW
Discuss this configuration →Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 6208, 5998 × 2098 × 2620, 2498, 2360 mm |
|---|---|
| Gross vehicle mass | 4250 kg |
| Curb weight | 2850 kg |
| Chassis model | JX6605TB-N6 |
| Wheelbase | 3750 mm |
| Engine model | JX4D20A6H |
| Engine displacement | 2000 ml |
| Engine power | 107 kW |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 185/75R16C, 185/75R16LT |
| Axles | 2 |
| Maximum speed | 160, 100 km/h |
| Rated passengers | 15, 10, 11, 12, 13, 14 |
