Rescue Utility Trucks
Jiangling Fushun Long-axis High-roof Rescue Vehicle
Model 5040XXH6QT
Jiangling Fushun Long-axis High-roof Rescue Vehicle supports emergency rescue, field repair and engineering response work.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Overall dimensions | 5998 × 2098 × 2900, 2820, 2620 mm |
|---|---|
| Gross vehicle mass | 4250 kg |
| Curb weight | 3250, 2980 kg |
| Chassis model | JX6605TB-N6 |
| Wheelbase | 3750 mm |
| Engine model | JX4D20A6H |
| Engine displacement | 2000 ml |
| Engine power | 107 kW |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 185/75R16C, 185/75R16LT |
| Axles | 2 |
| Maximum speed | 160, 100 km/h |
| Rated passengers | 6, 9 |
