Patient Transport Vehicles
Maxus V90 Short-axis Disabled Transport Vehicle
Model 5043XSC6QT
A short-axis disabled-transport vehicle based on the Maxus V90, configured for assisted passenger transfer.
Final equipment, certification and delivery terms are confirmed for each order.
Technical specifications
Technical specifications
Compare working capacity, dimensions, chassis, powertrain and running gear in one view. Emission labels follow the supplied Chinese standard; destination-market approval and any Euro classification must be confirmed separately.
| Rated passengers | 7,6 |
|---|---|
| Overall dimensions | 5180 × 2062 × 2420,2365 mm |
| Gross vehicle mass | 3550 kg |
| Curb weight | 2580 kg |
| Chassis model | SH6521J2DB |
| Wheelbase | 3000 mm |
| Engine model | SC20M150.1Q6 |
| Fuel type | Diesel |
| Emission standard | China VI (China VI (GB 17691-2018)) |
| Tires | 215/75R16LT |
| Axles | 2 |
| Maximum speed | 160 km/h |
| Special notes | 5043XSC6QT Vehicle Parameters Dimensions 5180 × 2062 × 2420,2365 mm Gross Weight 3550 kg Curb Weight 2580 kg Rated Passengers 7,6 Maximum Speed 160 km/h Chassis Model SH6521J2DB Tire Specification 215/75R16LT Number of Axles 2 Wheelbase 3000 mm Fuel Type Diesel Emission Standard China VI (GB 17691-2018)Engine Model SC20M150.1Q6 Displacement 1996 ml Power 110kw V90 Maxus V90 Short-axis Disabled Transport Vehicle |
